Broadband Power Limiter
Features:
- Reliable, lightweight: aluminum nickel-plated housing (corrosion-resistant, good heat dissipation), <100g for easy integration
- Connectors: SMA-K, compatible with standard interfaces
- Fully tested: loss, VSWR, power relationship, etc., with multidimensional curves ensuring stable performance
- Free Samples
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Huasen Microwave: Your Trusted Broadband Power Limiter Manufacturer
At Huasen Microwave Technology Co., Ltd., we're proud to be a leading manufacturer and supplier of high-performance Broadband Power Limiter. With over 30 a long time of ability in RF and microwave arrangements, our items offer unparalleled security for your touchy gear. We combine imaginative plan, thorough quality control, and customer-centric benefit to convey items that meet the requesting needs of telecom, aviation, and defense businesses.
Why Choose Our Broadband Power Limiter?
Our product stands out in the market for its exceptional performance and reliability. Here's why it's the top choice for telecom infrastructure providers and satellite communication systems:
- Ultra-Wideband Capability: Covers 1-50 GHz without signal distortion, perfect for 5G/6G applications.
- Robust Design: Aluminum housing with nickel plating ensures durability and excellent heat dissipation.
- Customizable Power Thresholds: Tailored protection from 20W to 100W to suit your specific needs.
- Compact and Lightweight: Weighs less than 100g, ideal for dense urban deployments.
- Comprehensive Testing: Rigorously tested for loss, VSWR, and power relationships to guarantee stable performance.
★[Star Product] HS2080LT30S
| Technical Indicators | ||||
|---|---|---|---|---|
| Parameter | Minimum | Typical Value | Maximum | Unit |
| Frequency Range | 2 | 8 | GHz | |
| Continuous Wave Input Power | 1 | CW | ||
| Peak Power (Duty Cycle < 10%, Pulse Width < 2μs) | 1 | W | ||
| Insertion Loss | 1.3 | 1.8 | dB | |
| Voltage Standing Wave Ratio | 1.4 | 1.5 | : 1 | |
| Leakage Value (Input Power ≤ 30dBm) | -17 | -15 | dBm | |
| Peak Power Leakage (Input Power ≤ 33dBm, Duty Cycle < 10%, Pulse Width < 2μs) | -14 | -12 | dBm | |
| Weight | 70.02 | g | ||
| Input/Output Connector | SMA-K | |||
| Cavity Material | Aluminum | |||
| Surface Treatment | Nickel Plating | |||
Product Features & Process
Our product employs advanced manufacturing processes to ensure superior performance:
- Precision CNC machining for tight tolerances
- Gold-plated PIN diodes for rapid response times
- Proprietary impedance matching techniques for minimal signal reflection
- Rigorous environmental testing to meet MIL-STD-810 standards
Standard Product Data Sheets
| Product Model | Frequency Range (GHz) | Maximum Continuous Wave Input Power (W) | Maximum Limiting Level (dBm) |
Insertion Loss (dB) |
VSWR | Connector Type |
|---|---|---|---|---|---|---|
| HS05210LT4WS | 0.05 - 21 | 4 | 22 | 1.3 | 1.8 | SMA-K |
| HS065.12LT2WS | 0.06 - 0.512 | 2 | -20 | 0.8 | 1.4 | SMA-K |
| HS15LT5WS | 0.1 - 0.5 | 5 | 20 | 0.3 | 1.1 | SMA-K |
| HS1.51.6LT1WS | 0.15 - 0.16 | 1 | -10 | 1.0 | 1.4 | SMA-K |
| HS1020LT6WS | 1 - 2 | 6 | 25 | 0.5 | 1.3 | SMA-K |
| HS1060LT50WS | 1 - 6 | 50 | 18 | 1.0 | 1.8 | SMA-K |
| HS10180LT6WS | 1 - 18 | 6 | 30 | 1.8 | 1.6 | SMA-K |
| HS10230LT1WS | 1 - 23 | 1 | -5 | 4.0 | 1.5 | SMA-K |
| HS10260LT0.5WS | 1 - 26 | 0.5 | 17 | 2.5 | 1.6 | SMA-K |
| HS2040LT200WS | 2 - 4 | 200 (Pulse) | 18 | 1.1 | 1.5 | SMA-K |
| HS2080LT1WS | 2 - 8 | 1 | -12 | 1.8 | 1.5 | SMA-K |
| HS20180LT6WS | 2 - 18 | 6 | 25 | 1.7 | 1.5 | SMA-K |
| HS20260LT5WS | 2 - 26 | 5 | 20.5 | 1.8 | 1.8 | SMA-K |
| HS4080LT1WS | 4 - 8 | 1 | -15 | 1.5 | 1.5 | SMA-K |
| HS60120LT1WS | 6 - 12 | 1 | -12 | 1.6 | 1.4 | SMA-K |
| HS75125LT10WS | 7.5 - 12.5 | 10 | 20 | 1.0 | 1.5 | SMA-K |
| HS80120LT6WS | 8 - 12 | 6 | 30 | 1.5 | 1.5 | SMA-K |
| HS120180LT1WS | 12 - 18 | 1 | -12 | 1.6 | 1.5 | SMA-K |
| HS120180LT6WS | 12 - 18 | 6 | 30 | 1.8 | 1.5 | SMA-K |
| HS290390LT1WK | 29 - 39 | 1 | 20 | 2.5 | 2.0 | 2.92-K |
Applications
The versatility of our Broadband Power Limiter makes it ideal for:
- 5G/6G base stations
- Satellite communication uplinks
- Radar systems
- Test and measurement equipment
- Military communications
Installation & Compatibility
Our limiter features standard SMA-K connectors, ensuring easy integration with your existing systems. Its compact size allows for flexible installation in tight spaces, making it perfect for upgrading legacy equipment or designing new, space-efficient solutions.
Quality Control & After-Sales
We stand behind our products with:
- ISO9001 certified quality management system
- RoHS and REACH compliance for environmental standards
- Comprehensive 1-year warranty
- Dedicated technical support team
Packaging and Shipping
Each product is individually packaged in anti-static bags and cushioned boxes to ensure safe transit. We offer expedited shipping options to meet your project timelines.
FAQ
Q1: What's the maximum power handling capability?
A1: Our standard models handle up to 100W, but we can customize for higher power requirements.
Q2: Is this limiter suitable for outdoor installations?
A2: Yes, it's designed to withstand harsh environments with an IP67 rating.
Q3: Can the power threshold be adjusted after installation?
A3: The threshold is factory-set, but we offer models with field-adjustable thresholds upon request.
Q4: How quickly does the limiter respond to power surges?
A4: Our limiters typically respond in nanoseconds, providing near-instantaneous protection.
Q5: Are there any special maintenance requirements?
A5: Our limiters are designed for minimal maintenance, but we recommend annual performance checks for optimal operation.
Contact Us
Ready to protect your valuable RF equipment with our industry-leading Broadband Power Limiter? Contact our expert team at sales@huasenmicrowave.com for personalized solutions and quotes.
