AC Power Amplifier
Features:
- Power: Built-in AC-DC conversion, supports AC220V/50Hz direct connection
- Applications: Communication, radar systems, etc. requiring high-power RF amplification
- Connectors: Various coaxial / waveguide types
- Free Samples
- Quality Assurance
- 24/7 Customer Service
Product Introduction
AC Power Amplifier: High-Performance RF Signal Amplification
Discover Huasen Microwave's cutting-edge AC Power Amplifier, designed to revolutionize your RF signal amplification needs. As a driving producer and provider, we pride ourselves on conveying top-tier arrangements that combine advancement with unwavering quality. Our item stands out with its coordinates AC-DC control supply module, rearranging your setup and boosting operational effectiveness.
| Product Type | Interface Type | ||
|---|---|---|---|
| Type Code | Meaning | Type Code | Meaning |
| PA | DC Power Amplifier Module | N | RF interface is N - 50K |
| ACPA | AC Power Amplifier Module | S | RF interface is SMA - 50K |
| HPA | High - Power Power Amplifier Module | K | RF interface is K2.92 - 50K |
| PAM | Complete Power Amplifier Machine | RF interface is waveguide interface | |
Why Choose Our AC Power Amplifier?
Our product is the go-to choice for professionals demanding superior performance and versatility:
- Seamless AC220V/50Hz mains power connection
- Customizable configurations to meet specific requirements
- High-efficiency power conversion with minimal heat dissipation
- Fail-safe redundancy options for uninterrupted operation
- Compatibility with global voltage standards (100V-240V)
- EMI shielding to protect sensitive equipment
★[Star Product] HS200470ACPAK
| Parameter | Minimum | Typical Value | Maximum | Minimum | Typical Value | Maximum | Unit |
|---|---|---|---|---|---|---|---|
| Frequency Range | 20 | 30 | 30 | 47 | GHz | ||
| Gain | 30 | 43 | 28 | 32 | dB | ||
| Gain Flatness | ±8.0 | ±3.0 | dB | ||||
| Gain Temperature Coefficient | ±3.0 | ±3.0 | dB | ||||
| Input VSWR | 1.6 | 1.8 | : 1 | ||||
| 1dB Compression Point | 24 | 28 | 26 | 29 | dBm | ||
| Saturated Output Power | 29 | 29 | dBm | ||||
| Isolation | -60 | -55 | dB | ||||
| Weight | 5270.27 | g | |||||
| Matching Impedance | 50 | Ω | |||||
| Input/Output Connector | 2.92-K | ||||||
| Cavity Material | Aluminum | ||||||
| Surface Treatment | Gray | ||||||
Product Features & Process
- Advanced thermal management for 24/7 operation
- Modular design for easy power scaling (500W to 20kW)
- Digital signal processing (DSP) for precise power control
- Rugged enclosure with IP54 rating for harsh environments
- Multiple interface options (SMA-K, 2.92-K, waveguide)
Our rigorous manufacturing process ensures each product meets the highest standards of quality and performance.
Standard Product Data Sheets
| Product Model |
Operating Frequency（GHz） |
Gain（dB） |
Gain Flatness（dB） |
Output Power | VSWR | Connector Type |
|
HS01220ACPA1WS |
0.01-22 |
26 |
±2 |
1W |
≤1.3 |
SMA-K |
|
HS025.5ACPA31WS |
0.02-0.55 |
43 |
±1 |
31W |
≤1.5 |
SMA-K |
|
HS140ACPA2.5WS |
0.1-4 |
31 |
±1 |
2.5W |
≤1.5 |
SMA-K |
|
HS730ACPA6WS |
0.7-3 |
41 |
±1 |
6W |
≤1.8 |
SMA-K |
|
HS760ACPA10WS |
0.7-6 |
37 |
±2 |
10W |
≤2 |
SMA-K |
|
HS10220ACPA4WS |
1-22 |
41 |
±5 |
4W |
≤2.5 |
SMA-K |
|
HS60180ACPA2WS |
6-18 |
35 |
±3 |
2W |
≤2.5 |
SMA-K |
|
HS180280ACPA2.5WK |
18-28 |
34 |
±2.5 |
2.5W |
≤3 |
2.92-K |
|
HS200470ACPA0.8WK |
20-47 |
32 |
±3 |
0.8W |
≤3 |
2.92-K |
Applications
Our products excel in various RF and microwave applications:
- Telecommunications infrastructure
- Radar systems
- Aerospace communications
- Defense electronic systems
- EMC testing facilities
- Scientific research laboratories
Crafted using premium copper and aluminum components, our amplifiers deliver unparalleled durability and conductivity.
Installation & Compatibility
Designed for hassle-free integration, our AC Power Amplifier offers:
- Plug-and-play setup with standard AC power connection
- Compact form factor for easy rack mounting
- Flexible input/output options for seamless system integration
- User-friendly interface for quick configuration and monitoring
Quality Control & After-Sales
We stand behind our products with:
- Rigorous quality assurance processes
- ISO9001, RoHS, and REACH certifications
- Comprehensive 1-year warranty
- 24/7 technical support
- Rapid response for urgent replacements
Packaging and Shipping
Your product will arrive safely, thanks to our:
- Custom-designed protective packaging
- Shock-absorbing materials for sensitive components
- Detailed handling instructions
- Worldwide shipping options
FAQ
Q: What sets your product apart from competitors?
A: Our integrated AC-DC module, customizable options, and superior efficiency make it a standout choice.
Q: Can the amplifier handle continuous high-load environments?
A: Yes, our warm administration framework guarantees dependable execution in requesting conditions.
Q: Are there options for redundant power supplies?
A: Absolutely, we offer dual power supply configurations for critical applications.
Q: How do you address EMI concerns?
A: Our intensifiers include progressed EMI protecting to secure adjacent delicate equipment.
Q: What type of technical support do you provide?
A: We offer 24/7 specialized back and fast reaction for critical issues.
Contact Us
Ready to lift your RF intensification capabilities? Reach out to our expert team at sales@huasenmicrowave.com for personalized assistance and to discuss how our AC Power Amplifier can meet your specific needs.
