waveguide wideband circulator

Huasen Microwave:Waveguide Wideband Circulator Product Introduction

The Waveguide Wideband Circulator manufactured by Huasen Microwave operates on the principle of ferrite materials' non-reciprocity. Under the action of a constant magnetic field, it enables unidirectional electromagnetic wave transmission in a specific sequence. Its core function is to serve as a transceiver duplexer for pulsed radar, achieving isolation between transmitted and received signals. It provides matching isolation between stages in the system to reduce signal reflection interference.

Our Product Classification and Technical Parameters

• Standard Waveguide Wideband Circulator

• Waveguide Differential Phase-Shift Circulator (for Wideband Applications)​​​​​​​：Application Scenario: Scenarios requiring phase control in high-power radar systems.​​​​​​​​​​​​​​

Design Features

-Power capacity decreases as frequency increases (higher heat dissipation challenges at high frequencies).

-Material optimization: Silver-plated copper is adopted in the high-frequency band to enhance thermal conductivity.​​​​​​​​​​​​​​

• High-Power Waveguide Wideband Circulator

Why Choose Our High Power WG Differential Phase Shift Circulator?

Waveguide Broadband Circulator (also referred to as Waveguide Full-Band Circulator) is a type of high-performance microwave passive component offered by Huasen Microwave, boasting the following advantages and features:

1..Broadband Coverage：Compared with standard waveguide circulators that typically have an operating bandwidth of ≤5%~15%, the waveguide full-band circulator can work within the entire waveguide dominant mode frequency band It enables "full-band" continuous use without the need for device replacement.

2.Excellent Electrical Performance Indicators：

• VSWR: Typ ≤1.35 (low freq) / ≤1.25 (high freq), excellent matching.
• Insertion Loss: ≤0.5 dB (general), down to ≤0.3 dB (high freq), high transmission efficiency.
• Isolation: ≥20 dB, anti-crosstalk, stable system performance.

3.Reliable Structure and Mature Technology

4.Wide Applications：Suitable for radar, communication, electronic countermeasure and test systems requiring broadband, high isolation and low insertion loss.Ideal for scenarios needing full waveguide band coverage without frequent device replacement.

Product Features & Process

• Reverse propagation and mutual coupling separate signals, avoiding reflection crosstalk.
• Average power up to 3500W, suitable for high-power applications such as radar.
• Customizable structural design (including waveguide, Y-junction, ferrite/magnet layout).
• High-precision milling/grinding of the metal Y-junction cavity to ensure dimensional and surface quality.
• Ferrite + cover plate fixation; magnets mounted at the center of the Y-junction and on the back of the cover plate,impedance matching adjustment column can be added as needed.

OEM

Huasen Microwave offers comprehensive OEM services, tailoring Waveguide Wideband Circulators to meet diverse project needs:

• We can customize waveguide type, operating frequency, and interface specifications based on core project requirements.
• We can customize branding and color coatings.
• We have a mature production system that ensures rapid response to large-volume orders and on-time delivery.
• From product selection to installation, commissioning, and system integration, we provide full technical support and professional guidance.
• We conduct standardized quality inspections on all products to ensure reliable performance and compliance with standards.

FAQ

1.What is a Waveguide Wideband Circulator?

A:Waveguide broadband circulators are non-reciprocal devices in the microwave/RF field that enable directional transmission of electromagnetic waves, allowing signals to propagate between specific ports without returning to the source.

2.What is the working principle of a waveguide broadband circulator?

The core working principle of a waveguide broadband circulator is to utilize the non-reciprocity of ferrite and combine it with an external magnetic field to achieve directional transmission of electromagnetic waves.

3.What are the performance parameters of a waveguide broadband circulator?

A:​​​​​​​​​​​​​​Frequency Range, Insertion Loss, isolation, VSWR, Power Rating, Operating Temperature Range, Number & Type of Ports, Dimensions & Weight.​​​​​​​

4.What are the main applications of Waveguide Wideband Circulators?

A:Radar systems, satellite communications, wireless communication infrastructure, test and measurement instruments, defense and aerospace, power amplifier systems.

Contact Us

For inquiries or customized Waveguide Wideband Circulator solutions, please reach out to our expert team at sales@huasenmicrowave.com. Let's collaborate to elevate your RF performance today!
