Waveguide Elevating Platform
High Strength Load-bearing: 40-80kg
Military-grade Stability: Full metal structure ensures secure equipment installation
Typical Application Scenarios:
- Antenna Testing: Used with rotating joints and other products
- System Integration: Supports waveguide coaxial joint components
- Millimeter-wave Experiments: Compatible with 26.5-40GHz frequency devices
- Free Samples
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Huasen Microwave: Precision-Engineered Waveguide Elevating Platform for Optical Excellence
Huasen Microwave Technology Co., Ltd., a leading manufacturer of high-frequency microwave and millimeter-wave components, proudly presents our cutting-edge Waveguide Elevating Platform (SJPT). With over three decades of expertise, we deliver unparalleled precision and reliability in RF and microwave solutions. Our product stands out for its compact design and exceptional load-bearing capacity, making it the ideal choice for optical component producers seeking superior performance and stability.
Why Choose Our Waveguide Elevating Platform?
Our product offers a perfect blend of innovation and customization:
- Precision Engineering: Achieve micron-level accuracy with our high-precision design.
- Versatile Sizing: Available in various dimensions to suit your specific needs.
- Robust Load Capacity: Support 40kg to 80kg static loads effortlessly.
- Flexible Height Adjustment: Enjoy a wide range from 36mm to 260mm.
- Compact Footprint: Easy to deploy in labs or on-site environments.
- Durable Construction: Optimized materials ensure longevity in demanding conditions.
- Customizable Solutions: Tailor-made options to meet your unique requirements.
Standard Product Data Sheets
|
Type Code |
Meaning |
Dimensions (mm) |
Static Load Bearing |
|
HSSJPT-X |
Small Adjustable Support |
50×40×(36-89) |
40(kg) |
|
HSSJPT-Z |
Medium Adjustable Support |
70×55×(36-132) |
40(kg) |
|
HSSJPT-D |
Large Adjustable Support |
100×75×(36-132) |
50(kg) |
|
HSSJPT-T1 |
Extra large 1 Adjustable Support |
140×100×(55-255) |
60(kg) |
|
HSSJPT-T2 |
Extra large 2 Adjustable Support |
160×120×(56-260) |
80(kg) |
Product Features & Process
Our Waveguide Elevating Platform boasts:
- Low thermal expansion materials for consistent performance
- Vibration-dampening design to maintain optical alignment
- High-rigidity structure for continuous operation
- EMI/RFI shielding for seamless integration with sensitive optics
- Precision-machined components ensure smooth, accurate adjustments
Applications
Ideal for various industries and equipment:
- Laser systems and optical benches
- Fiber-optic alignment and testing
- Photonic device manufacturing
- Aerospace and defense optical systems
- Precision measurement instruments
Installation & Compatibility
Our platforms are designed for easy integration:
- Plug-and-play setup with most optical systems
- Compatible with standard optical tables and breadboards
- Modular design allows for quick reconfiguration
- Optional adapters available for specialized equipment
Quality Control & After-Sales
We prioritize your satisfaction:
- Rigorous quality checks at every production stage
- ISO9001, RoHS, and REACH certified
- Comprehensive 1-year warranty
- Dedicated technical support team
Packaging and Shipping
Your product arrives safely:
- Custom-fitted, shock-absorbing packaging
- Detailed installation guide and calibration instructions
- Optional on-site setup and training available
